TrailMaster TM06-110
$649.00
* MSRPs exclude tax, license, registration, destination charge and dealer-installed options. Dealer Prices may vary.
The TM 06-60 (AUTO-EStart) is a great Pee Wee size dirt bike. It has a smooth 60cc 4 stroke 2.4 hp engine with electric start (No Kick Start) that is fully AUTOMATIC…turn the throttle and go for those beginners…with an easily adjustable throttle limiter keeping the speed set to what Mom and Dad feels safe. It has a seat height of 22” for with fully supporting training wheels for the kiddies to learn the fun of riding without the spills. It is available in red, blue, and green colors. The TM06 features front and rear disc brakes, 10” front & Rear Tire and a heavy duty frame built for durability! This is sure to be a HOT seller!
Tech Specs
| Engine System | |
| Engine Type | 60cc, Automatic, Single cylinder, 4 stroke, Air cooled |
| Displacement | 60 ml |
| Shift Type | Automatic clutch, One gear |
| Start Type | Electric Start Only |
| Bore x Stroke | Ф52.4×49.5mm |
| Max Power | 1.8 / 7000 kw/r/min |
| Max Torque | 2.4 / 6500 N.m/r/min |
| Compression Ratio | 10 : 1 |
| Engine Oil #： | SJ5W一30 |
| Ignition | CDI |
| Drive Train | #T8F，14/74T |
| Size Data | |
| Overall Size(L*W*H) | 1270*590*780mm/50"X23.23"X30.71" |
| Wheel Base | 34.84" |
| Seat Height | 22.05" |
| Ground Clearance | 7.09" |
| Fuel Capacity | 1.8L / 0.4 Gal. |
| Wheels | Fr. & Rr. Both Steel 1.40×10/￠12 Rims, Cast Hubs and Rim |
| Tire | Fr. & Rr. Both 2.50x10 ,Knobby tires |
| Frame/Suspension/Brake system | |
| Frame | Cradle Type Steel Tube Frame |
| Front Fork | L=520mm Inverted Hydraulic Non Adjustable Forks, 50mm Travel |
| Rear Shock | L=200mm Non Adjustable Shock, 30mm Travel |
| Swing-Arm | Forged Steel Swingarm |
| Handle Bar | Steel handle bar |
| Front Brake | Mechanical Brakes, 140mm Disc |
| Rear Brake | Mechanical Brakes, 140mm Disc |
| Exhaust | Aluminium Alloy Exhaust Pipe |
| Packing and Loading | |
| Packing Size | 44.1*12.6*22.44 inch |
| N.W/LBS | 72.6 LBS |
| G.W/LBS | 81.4 LBS |
Key Features
• Powerful 4 stroke ZhongShen oil cooled 156ml, 14.3 HP engine
• Kick start, 4 gear manual clutch
• 53.3“ wheel base and 34.6” seat high
• 780mm Inverted Hydraulic Forks, 150mm Travel
• 410mm Spring Pre-load None-Adjustable Shock
• Front tire 19”/Rear Tire 16”
• LED Headlight
• Foldable Clutch & Brake Lever
• Alloy Bracket Handguard
• TrailMaster Ribbed Seat
Manuals & Instructions
TM06 Assembly Video
