TrailMaster SX125
$1,749.00
Trailmaster cooperating with JHL Offroad introduces The SX125, a premium PRO-Series mid size
dirt bike. It has both a kick start and a “ELECTRIC START” to start a high performance extremely
reliable Zhongshen 123cc 4 stroke 8.4hp engine with a seat height of 32.7”, wheels size of
19/16, and a slim weight of 189lbs. It is available in red, blue, and green colors. The SX125
features a 4 speed manual transmission with front and rear disc brakes, and inverted front
shock.
This is sure to be a HOT seller! Additional standard premium items with our Pro-Series line include;
electric and kick start, famous brand Zongshen 125cc engine, new frame design to achieve
ultimate performance, High performance inverted front shock absorber, 33” seat high perfect
for wide groups of riders, Wide high quality non-slip seat for comfortable riding, Nitrogen air
gas rear shock absorber w/aluminum linkage, Performance stainless steel muffler
Alloy handle bar & upper and lower triple clamps, Alloy foldable handle levers, High quality
reinforced alloy rims and hubs, Large 19” front and 16”d rear Yuanxin Tires, Superior quality
front and rear disc brakes.
Tech Specs
General Information
• BS125 Single cylinder, four stroke, air-cooling
• Displacement 123.67 CC
• Max Power 8.4 hp
• Max Torque 8.8/5500(1±1.5%)
• Compression Ratio 9.0:1
• Shift Type: Four gear, non-circulate gear
• Start Type Electric / Kick Start
• Ignition CDI
• Min. Fuel Consumption: ≤ 367g/kw.h
• Min turning radius: 1900 mm
• Lubricant Type # SF15W/40
• Transmission: Chain Drive
Size Data
• Overall Size (L x W x H) 71.31 x 29.16 x 43.34 Inch
• Wheel Base 49.25 Inch
• Seat Height 32.70 Inch
• Ground Clearance 13.39 Inch
• Fuel Capacity 1.56 Gal.
• Alloy 19/ 16 Rims, Alloy Hubs
• Tires YUANXING FT: 70/100-19 - RR: 90/100-16
Frame/Suspension/Brake/Wheel System
• High quality Steel Frame
• Front Fork Inverted , non-Adjustable
• Rear Shock Alloy U&D connector, non-Adjustable
• Triple Clamps Alloy
• Handle Alloy and Foldable
• Front Brake Disc
• Rear Brake Disc
• Exhaust Stainless
Packing and Loading
• Packing Size 63.82*17.92*33.49 Inch
• N.W/LBS 189.2 LBS
• G.W/LBS 237.6 LBS
Configurations And Specifications Subject To Change Without Notice. “BV POWERSPORTS, LLC”
Key Features
• With both electric and kick start
• Famous brand Zongshen 125cc engine
• Newly frame design to achieve ultimate performance
• High performance inverted front shock absorber;
• 33” seat high perfect for wide groups of riders
• Wide and high quality non-slip seat for comfortable riding
• Nitrogen air gas rear shock absorber w/aluminum linkage
• Performance stainless steel muffler
• Alloy handle bar
• Alley upper and lower triple clamps
• Alloy foldable handle levers
• High quality reinforced alloy rims and hubs
• Large 19” front and 16”d rear Yuanxin Tires
• Superior quality front and rear disc brakes
